| Rám |
C:62® Monocoque Advanced Twin Mold Technology, Aluminium 6061 T6 Rear Triangle, Efficient Trail Control, FSP 4-Link, Agile Trail Geometry, Boost 148, UDH™, Full Integrated Battery, Advanced Internal Cable Routing |
| Velikosti |
Size Split: 27.5: S // 29: M, L, XL |
| Odpružená vidlice |
Fox 36 Float Rhythm GRIP, Tapered, 15x110mm, E-Bike Optimized, 150mm |
| Tlumič |
Fox Float Performance, 230x60mm (27.5: 210x55mm), Adjustable LSR w/ 2-Pos. Lever |
| Redukce do tlumiče |
Front: 30x8mm, Rear: DU-Bushing 12.7mm |
| Motor |
Bosch Drive Unit Performance Line CX max. 100Nm (BDU38) |
| Remote |
Bosch Mini Remote |
| Baterie |
Bosch PowerTube 800 |
| Displej |
Bosch Kiox 400C |
| Nabíječka |
Bosch 4A |
| ABS technologie |
Bosch ABS Pro |
| Brzdy |
Shimano XT BR-M8220, Hydr. Disc Brake w/ Front ABS (203/203) |
| Přehazovačka |
Shimano XT Di2 RD-M8260-SGS, 12-Speed, Electronic Shifting System |
| Řazení |
Shimano XT Di2 SW-M8250-IR, Direct Attach |
| Kliky |
ACID MTB Hybrid Pro, 27.5: 36T // 29: 34T |
| Kazeta |
Shimano Deore CS-M6100, 10-51T |
| Řetěz |
Shimano CN-M6100 |
| Vodítko |
Reverse Flip-Guide E-Chain Guide, Direct Mount, I-Plate |
| Hlavové složení |
ACROS AZF-675, ICR, Top Zero-Stack 1 1/2" (ZS 56mm), Bottom Zero-Stack 1 1/2" (ZS 56mm), Fiber Inserts for Angle Adjustment, X-Connect Interface |
| Představec |
CUBE Performance Stem E-MTB 35, FPI-Link |
| Řídítka |
CUBE Rise Trail Bar 35 |
| Gripy |
ACID Disrupt |
| Kola |
Newmen Performance 30 base/strong, 28/32 Spokes, 15x110mm / 12x148mm, Tubeless Ready |
| Přední plášť |
Conti Kryptotal Front, Enduro Soft, Tubeless Ready, 2.4 |
| Zadní plášť |
Conti Kryptotal Rear, Downhill Soft, Tubeless Ready, 2.4 |
| Sedlo |
ACID Venec EMTB Trail 140 |
| Sedlovka |
CUBE Dropper Post, Handlebar Lever, Internal Cable Routing, 31.6mm |
| Pedály |
ACID PP MTB |
| Barva |
stellar´n´grey |
| Hmotnost |
24,8 kg |
